  • Heat exchanger tube expander machine

Heat exchanger tube expander machine

Disposable expansion tube: 2-12 pcs optional

Drive type: servo motor

Touch screen languages: English and Chinese

Maximum length: default is 5 meters (10-20 meters optional)

Tube material: aluminum, stainless steel, copper

Machine Overview

This is a heat exchanger tube expander machine driven by a servo motor. The servo motor drives multiple sets of rollers to increase speed and torque output. The device can easily expand stainless steel and titanium alloy tubes.

Moreover, the expansion machine adopts a flexible design that allows users to quickly replace tools to adapt to different pipe diameters and spacing layouts. This flexible design can improve the efficiency of the factory and reduce costs.

The heat exchanger tube expander machine uses a PLC as the control center, and the parts of the control system come from internationally renowned brands such as Mitsubishi and Siemens. The system allows users to preset the production parameters of the product through a touch screen, and the control system presets various production modes.

Heat exchanger tube expander machine data

ITEMDATA
Power supply380v/50Hz
Language of Touch screen English & Chinese
Drive typeservo motor
Delivery time45 days
Maximum length5-20 meters optional
Pipe materialcopper
aluminum
stainless steel
Heat exchanger tube expander machine
Flexible expander machine

Tube expander machine advantage

1, Efficient production:

Multiple sets of gears drive the movement speed of the needle, achieving high-speed production

2, Accurate control:

The Servo motor drive can accurately control the expansion length

3, Wide application range:

It can expand different raw material pipes, and tool replacement can adapt to different sizes, with the high versatility of the Heat exchanger tube expander machine

4, Low maintenance cost:

Only need to regularly add lubricating oil to the gears, without any other maintenance costs

5, Strong durability:

The expansion ball is made of tungsten steel material, which will not wear out after long-term use

6, Easy to operate:

The design of a user-friendly control interface allows workers to operate the machine without the need for training

Heat exchanger tube expander machine video

Support and Services

We provide installation and technical training services for this machine, but the buyer needs to cover the expenses for our engineers, such as airfare, hotel, visa, and food.

But so far, we haven’t provided this service to any customers.

Because customers can easily install this tube expander machine according to our machine manual, and use it smoothly.

Our engineers wrote this machine’s manual from a beginner’s perspective. They provided a detailed introduction to various aspects, such as installing the machine, setting it up for the first time, using it, and maintaining and servicing it.

When you get this machine, you can use it easily without paying for installation and training.

What are the working sizes of the tube expander machine?

Our equipment covers almost all sizes in the HVAC industry, and it also has a wide range of applications in the heat exchanger industry. You just need to tell us your tube diameter and hole spacing, and we can customize this machine for you.

The following dimensions are the standard sizes for heat exchangers.

  • φ 5*19.5*11.2
  • φ 5*19.5*11.2
  • φ 7*21.0*12.7
  • φ 20.5*12.7
  • φ 7.94*22.0*19.05
  • φ 9.52*25.4*22
  • φ 9.52*25.0*21.65
  • φ 10.2*20.0*15.5
  • φ 12.7*31.75*27.5
  • φ 15.88*38.0*32.91
  • φ 15.88*38.1*22.2
  • φ 16*50*50
  • φ 19.4*50.8*38.1
  • φ20*34.0*29.5

Q & A

Q: What is the fastest delivery time for this machine?

A: The fastest delivery time for this machine is 42 days.

Q: Can this machine expand 12 pipes at once?

A: Yes, it can.

Q: How to control the length of pipes?

A: The length of the tube can be set on the screen, and the servo motor can precisely control the length.
