Product Description
This leak testing equipment detects whether a car’s aluminum radiator is leaking. It has two independent workstations that can test two products simultaneously.
Each workstation has a 7-inch touch screen that displays the pressure changes of the test curve, allowing engineers to check the test data visually.
It can connect to a printer, print labels, and record test data for each tested product.
Leak testing equipment Technical Parameters
| ITEM | DATA |
| Test pressure | 0.1-0.8 mPa |
| External dimensions | 220*120*190cm |
| Machine color | default silver gray |
| Test workstation | 2 pcs |
| Medium | Compressed air |
| Leakage alarm | Yes |
| Test object | radiator, heater |
| Touch screen | 7 inches |
| Display mode | numbers and curves |
Features of leak testing equipment
Its appearance results from spray painting and baking technology, and it looks like a car. The surface of the workbench is wrapped in a 2mm solid and durable stainless steel 304 plate.
The machine has been installed with a dashboard and digital display pressure gauge, and users can adjust different test pressures according to product technical requirements.
This machine’s power supply is 24V, which can be used normally with an ordinary household power supply and is very energy-saving.
This device will not make any noise during testing, so it will not affect the surrounding environment.
This leak-testing equipment has specialized tools that can easily adapt to various radiator sizes by replacing the rubber gasket.
Product quick details
- Test medium: Compressed air
- machine name: leak testing equipment
- Test tube: 1 piece
- Pressure range: 0.05-0.6mPa (optional)
- Test time: 1-999 seconds
- Testing tool: Customized cylinder
- Leakage detection range: 0.1-30L/min,
- Test accuracy: ±1%
- Test workstation: 1-6 workstations optional
- Test temperature: Room temperature
- Test products: engines, radiators, heat exchangers, heaters, automotive pipelines, etc
- Air source: 0.2-0.8 MPa.
Leak testing equipment working video
Other car radiator machines
Vacuum packaging machine of radiator and condenser
Machine Overview Industrial vacuum packaging machines mainly package products such as car radiators and condensers. It uses vacuum pressure to adsorb plastic film onto cardboard. This packaging machine is also widely used in other fields,…
Tank Clinching Machine for car and truck radiators
Equipment usage The Tank Clinching Machine actively assembles aluminum radiators designed for truck engines. It combines the radiator core, a sealing gasket, and plastic tanks, securely forming a closed container. This active process highlights the…
Radiator crimping machine of Fully automatic production
Machine outline This radiator crimping machine is mechanical equipment used in automotive radiator factories. Its main function is to press the radiator core and plastic tank together to form a complete radiator. The machine is…
Radiator core assembly machine | condenser core builder
Equipment use The radiator core assembly machine is used to assemble the Automobile radiator core, condenser core, Intercooler core, and oil cooler core. The machine works smoothly, and assembly is quick, easy to operate, low…
Tools for testing machines
This is a non-standard cylinder with rubber sealing rings installed on the cylinder, and its size meets the testing requirements of the car radiator,
As is well known, there are many types of radiators in the after-sales market, and the size of the water outlet varies. Therefore, this cylinder adopts a flexible design and replaces the sealing ring to adapt to various radiators.
Q & A
A: This machine can test It, but testing tools must be making to secure and seal the engine body.
A: This leak testing equipment’s fastest delivery time is 25 days
A: Our machine has an oil-water separation device. You only need to connect the pipes here, which is very easy.
